Bosch Rexroth Fixed Hydraulic Cylinder 100mm Stroke, 2952993400
This steel hydraulic cylinder from the RSM Series delivers 10 tonnes of power with a 4.4" stroke. Featuring mounting holes for easy fixturing, CR-400 couplers, and chrome-plated steel plungers, it's built for reliable, heavy-duty performance.
| Specification | Details |
|---|---|
| Model Number | 2952993400 |
| Type | Fixed Hydraulic Cylinder (Series 1X) |
| Stroke Length | 100 mm |
| Bore Size | 32 mm |
| Pull Force | 8.79 kN |
| Closed Length | 293 mm |
| Extended Length | 393 mm |
| Maximum Operating Pressure | 160 bar |
| Static Proof Pressure | 240 bar |
| Flow Rate (Out) | 4.8 L/min |
| Flow Rate (In) | 3.3 L/min |
| Weight | 550 g |
| Material | Carbon steel body |
| Seals | NBR (Nitrile)/Polyurethane seals |
| Operating Temperature Range | -20°C to +80°C |
| Recommended Hydraulic Fluid | Mineral oil-based fluids |
| Mounting Compatibility | ISO 3320 |
| Compliance | Compatible with ISO mounting styles and fixings |
